22 METERS TUGBOAT
₱6,500.00
🔒 Log in to buy
Create a free account
Free registration · verify your email · pay with QR Ph
Description
13 Sheet Plan available in CAD Format: General Arrangement Plan , Lines Plan And Table Of Offsets, Capacity Plan, Construction Plan, Midship & Other Sections, Shell Expansion Plan, Hydrostatic Curves, Cross Curves, Electrical Plan, Tank Filling & Air Vent Piping, Fire Control And Life Saving Plan, Welding Schedule, Specification & Arrangement Of Main Propulsion And Auxiliary Machineries.
